JIS S45C Cylinder Rod / Oil Cylinder Piston Rod 25.4mm

JIS S45C Cylinder Rod / Oil cylinder piston rod 25.4mm
Oil cylinder piston rod parameters:
Axle diameter: Ø 6~130mm
standard length: 2000~7000mm
Tensile strength: 570~690 N/mm2
yield strength: >345 N/mm2
Stretch length: >17%
Chrome plating: 20Micron±5
Surface roughness: Ra0.2~Ra0.4
Chromium plating hardness: Minimum HV800
Tolerances: f8, h8

Cylinder Rod / Oil cylinder piston rod application:
For medium carbon steel piston rod: JIS S45C / DIN CK45 / SAE 1045和JIS S55C,Steel bar in precision cold pumping, higher tensile, hard chromium plating, the plating rod wear, rust, corrosion, uniform hardness, and then through other processing, such as lathes, milling, drilling and so on. The mandrel is suitable for all kinds of piston rods, cylinders, hydraulic cylinders, mechanical guide rods, brother columns, punch, press, ladders, crane, plastic injection machines, sealing machines, packaging machinery automation equipment, etc.

Specifications of Cylinder Piston Rod

25.4mm Oil Cylinder Piston Rod

JIS S45C Piston Rod

Cylinder Seamless Precision Steel Tube
